Capacity |
: |
10000VA / 9000W |
|
UPS type |
: |
Tower |
|
Input phase |
: |
Single phase with ground |
|
Input nominal voltage |
: |
10000VA: 208/220/230/240VAC |
|
Input voltage range |
: |
10000VA: 110-300VAC (Based on load at 50%), 176-300VAC (Based on load at 100%) |
|
Input frequency |
: |
10000VA: 46-54Hz or 56-64Hz |
|
Input power factor |
: |
≧ 0.99 @ nominal voltage (100% load) |
|
Output voltage regulation |
: |
±1% |
|
Output frequency |
: |
10000VA: Synchronized range: 46 - 54Hz or 56 - 64Hz, Battery mode: 50Hz or 60Hz ± 0.1Hz |
|
Output current crest ratio |
: |
3:01 |
|
Output harmonic distortion |
: |
10000VA: ≦ 3% THD (Linear load), ≦ 5% THD (Non-linear load) |
|
Battery type and number |
: |
10000VA - 12V/9Ah x 16pcs |
|
Battery recharge time |
: |
10000VA - 9 hours to 90% capacity |
|
Alarm |
: |
Battery mode - Sounding every 4 seconds |
|
|
: |
Low battery - Sounding every second |
|
|
: |
Overload - Sounding twice every second |
|
|
: |
Faulty - Continuously sounding |
|
LCD indicators |
: |
Load level, battery level, AC mode, battery mode, bypass mode, and fault indicators |
|
Front panel |
: |
Status LED, function keys, LCD display |
|
Communication |
: |
Smart RS232 and USB port |
|
Code |
: |
UPPL-53 |
