Camera |
: |
|
|
Image Sensor |
: |
5 MP CMOS |
|
Max. Resolution |
: |
2560 (H) × 1944 (V) |
|
Min. Illumination |
: |
0.0005 Lux @ (F1.0, AGC ON), 0 Lux with White Light |
|
Shutter Time |
: |
PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s |
|
Day & Night |
: |
Color |
|
Angle Adjustment |
: |
Pan: 0 to 360°, Tilt: 0 to 90°, Rotation: 0 to 360° |
|
Signal System |
: |
PAL/NTSC |
|
Lens |
: |
|
|
Lens Type |
: |
3.6 mm, 6 mm fixed lens |
|
Focal Length & FOV |
: |
80.1° (3.6 mm), 49.3° (6 mm) |
|
Lens Mount |
: |
M16 |
|
Illuminator |
: |
|
|
Supplement Light Type |
: |
White Light |
|
Supplement Light Range |
: |
Up to 40m |
|
Image |
: |
|
|
Image Parameters Switch |
: |
STD/HIGH-SAT |
|
Image Settings |
: |
Brightness, Sharpness, Mirror, Smart Light, AGC |
|
Frame Rate |
: |
TVI: 5MP@20fps, 4MP@30fps, 4MP@25fps, 1080p@30fps, 1080p@25fps CVI: 4MP@30fps, 4MP@25fps AHD: 5MP@20fps, 4MP@30fps, 4MP@25fps CVBS: PAL/NTSC |
|
Day/Night Mode |
: |
Color |
|
Wide Dynamic Range (WDR) |
: |
≥130 dB |
|
Image Enhancement |
: |
BLC, HLC |
|
White Balance |
: |
Auto/Manual |
|
Interface |
: |
|
|
Ethernet Interface |
: |
Switchable TVI/AHD/CVI/CVBS |
|
General |
: |
|
|
Power |
: |
12 VDC ± 25%, Max. 4.9 W *You are recommended to use one power adapter to supply the power for one camera |
|
Material |
: |
Metal |
|
Dimension |
: |
82.6 mm × 77.1 mm × 220.4 mm |
|
Weight |
: |
Approx. 565 g |
|
Approval |
: |
|
|
Protection |
: |
IP67 |
|
Code |
: |
PCC-268 |
