Camera |
: |
|
|
Image Sensor |
: |
1/3" progressive scan CMOS |
|
Max. Resolution |
: |
2560 × 1440 |
|
Min. Illumination |
: |
Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR |
|
Shutter Time |
: |
1/3 s to 1/100,000 s |
|
Day & Night |
: |
IR cut filter |
|
Angle Adjustment |
: |
Pan: 0° to 360°, tilt: 0° to 180°, rotate: 0° to 360° |
|
Lens |
: |
|
|
Lens Type |
: |
Fixed focal length, 2.8 and 4 mm optional |
|
Focal Length & FOV |
: |
2.8 mm, horizontal FOV 98.0°, vertical FOV 53.1°, diagonal FOV 114.7° 4 mm, horizontal FOV 78.7°, vertical FOV 43.1°, diagonal FOV 92.3° |
|
Lens Mount |
: |
M12 |
|
Iris Type |
: |
Fixed |
|
Aperture |
: |
F2.0 |
|
Illuminator |
: |
|
|
Supplement Light Type |
: |
IR |
|
Supplement Light Range |
: |
Up to 30 m |
|
Smart Supplement Light |
: |
Yes |
|
IR Wavelength |
: |
850 nm |
|
Image |
: |
|
|
Image Parameters |
: |
Switch |
|
Image Settings |
: |
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
|
Day/Night Mode |
: |
Auto, Schedule, Day, Night |
|
Wide Dynamic Range (WDR) |
: |
120 dB |
|
Image Enhancement |
: |
BLC, 3D DNR |
|
Video |
: |
|
|
Main Stream |
: |
50 Hz: 20 fps (2560 × 1440) 25 fps (1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2560 × 1440) 30 fps (1920 × 1080, 1280 × 720) |
|
Sub-Stream |
: |
50 Hz: 25 fps (640 × 480, 640 × 360) 60 Hz: 30 fps (640 × 480, 640 × 360) |
|
Video Compression |
: |
Main stream: H.265/H.264/H.264+/H.265+ Sub-stream: H.265/H.264/MJPEG |
|
Video Bit Rate |
: |
32 Kbps to 8 Mbps |
|
H.264 Type |
: |
Baseline Profile/Main Profile/High Profile |
|
H.265 Type |
: |
Main Profile |
|
Nework |
: |
|
|
Protocols |
: |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS |
|
Simultaneous Live View |
: |
Up to 6 channels |
|
API |
: |
Open Network Video Interface, ISAPI |
|
User/Host |
: |
Up to 32 users. 3 levels: administrator, operator and user |
|
Client |
: |
iVMS-4200, Hik-Connect |
|
Web Browser |
: |
Plug-in required live view: IE 10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+ |
|
Interface |
: |
|
|
Ethernet Interface |
: |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
|
On-Board Storage |
: |
Built-in memory card slot, support microSD card, up to 256 GB |
|
Built-in Microphone |
: |
Yes |
|
Reset Key |
: |
Yes |
|
Event |
: |
|
|
Basic Event |
: |
Motion detection, video tampering, exception |
|
Linkage |
: |
Upload to FTP, notify surveillance center, send email -UF also supports: upload to memory card, trigger recording, trigger capture |
|
General |
: |
|
|
Power |
: |
12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug PoE: IEEE 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W |
|
Material |
: |
Metal & Plastic |
|
Dimension |
: |
177.6 mm × 66.2 mm × 67.8 mm |
|
Weight |
: |
Approx. 270 g |
|
Approval |
: |
|
|
EMC |
: |
FCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
|
Safety |
: |
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015) |
|
Environment |
: |
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
|
Protection |
: |
IP67 (IEC 60529-2013) |
|
Code |
: |
PCC-272 |
