Image Sensor |
: |
1/2.7" CMOS sensor for high-resolution imaging |
|
|
: |
Up to 5MP (2880×1620) at 30fps, providing clear and detailed video. |
|
Lens |
: |
5mm–115mm motorized lens with 23x optical zoom, allowing for detailed close-ups. |
|
Field of View |
: |
Horizontal: 58°–3.2°, Vertical: 33.9°–1.9°, Diagonal: 64.8°–3.6°. |
|
IR Illumination |
: |
Equipped with 7 IR LEDs, offering a night vision range of up to 150 meters |
|
Pan & Tilt Capabilities |
: |
|
|
Pan Range |
: |
360° continuous rotation. |
|
Tilt Range |
: |
-16° to 90°, with preset speeds up to 80°/s. |
|
Preset Positions |
: |
Supports up to 500 preset positions for quick access to critical areas. |
|
Cruise & Scan |
: |
16 cruise paths and 8 scan patterns, each with programmable sequences. |
|
Smart Features |
: |
|
|
Video Compression |
: |
Supports H.265, H.264, and MJPEG formats for efficient bandwidth usage. |
|
Audio Compression |
: |
G.711A/G.711U/ADPCM_D/AAC_LC. |
|
Wide Dynamic Range (WDR) |
: |
120dB for clear images in challenging lighting conditions. |
|
Noise Reduction |
: |
3DNR for enhanced image quality |
|
Privacy Masking |
: |
Up to 24 regions to protect sensitive areas. |
|
Network & Storage |
: |
|
|
Protocols Supported |
: |
HTTP, HTTPS, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP v1/v2/v3, DHCP, DNS, DDNS, NTP, SMTP, TLS v1.2, SSL, 802.1x, QoS, IPv4, IPv6, PPPoE, SSH, Unicast, Multicast, ARP, RTP, SRTP, FTP, SFTP. |
|
Storage |
: |
Built-in Micro SD card slot, up to 512 GB. |
|
Remote Access |
: |
Supports P2P, ONVIF (Profile S/T/G/M), SDK, CGI, Milestone, RTSP, RTMP. |
|
Build & Environmenta |
: |
|
|
Power Supply |
: |
DC12V±10%; PoE: IEEE 802.3at |
|
Material |
: |
Durable metal and plastic construction. |
|
Dimensions |
: |
161 x 276mm |
|
Weight |
: |
2.2kg |
|
Software & Compatibility |
: |
|
|
Client Software |
: |
Easy7 VMS. |
|
Mobile App |
: |
Compatible with EasyLive Plus. |
|
Web Client |
: |
Supports browsers like IE10+, Firefox52+, Edge89+, Safari11+, Chrome57+. |
|
User Management |
: |
Up to 32 users with 4 user levels. |
|
Code |
: |
PCC-279 |
