Camera |
: |
|
|
Image Sensor |
: |
1/2.7" Progressive Scan CMOS |
|
Max. Resolution |
: |
2688 × 1520 |
|
Min. Illumination |
: |
0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR |
|
Shutter Time |
: |
1/3 s to 1/100,000 s |
|
Day & Night |
: |
ICR Cut |
|
Angle Adjustment |
: |
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
|
Wide Dynamic Range |
: |
120dB |
|
Lens |
: |
|
|
Focus |
: |
Fixed |
|
Lens Type & FOV |
: |
1.68mm @ F2.0, horizontal FOV 180°, vertical FOV 101°, diagonal FOV |
|
Lens Mount |
: |
M12 |
|
Aperture |
: |
F2.0 |
|
DORI |
: |
|
|
DORI |
: |
Detect: 3.6 m, observe: 1.4 m, recognize: 0.8 m, identify: 0.4 m |
|
Illuminator |
: |
|
|
IR Range |
: |
20 m |
|
Wavelength |
: |
850nm |
|
Smart Supplement Light |
: |
Yes |
|
Image |
: |
|
|
Image Settings |
: |
Saturation;brightness;contrast;sharpness;rotate mode;white balance;AGC |
|
Day/Night Mode |
: |
Day, Night, Atuo, Schedule |
|
Image Enhancement |
: |
BLC;HLC;EIS;Lens Distortion;3D DNR |
|
Privacy Mask |
: |
4 regions of privacy mask |
|
Video |
: |
|
|
Main Stream |
: |
50Hz: 25fps (2688 × 1520, 2304 × 1296, 1920 × 1080, 1280 x 720) 60Hz: 24fps (2688 × 1520), 30fps (2304 × 1296, 1920 × 1080, 1280 x 720) |
|
Sub-Stream |
: |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240); 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
|
Video Compression |
: |
Main stream: H.265+/H.265/H.264+/H.264; Sub-stream: H.265/H.264 /MJPEG |
|
Video Bit Rate |
: |
32 Kbps to 16 Mbps |
|
H.264 Type |
: |
Main Profile/High Profile |
|
H.265 Type |
: |
Main Profile |
|
Nework |
: |
|
|
Protocols |
: |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets |
|
Simultaneous Live View |
: |
Up to 6 channels |
|
API |
: |
ONVIF (PROFILE S, PROFILE G), ISAPI, SDK |
|
User/Host |
: |
Up to 32 users 3 levels: Administrator, Operator and User |
|
Client |
: |
iVMS-4200, Hik-Connect, Hik-Central |
|
Web Browser |
: |
Plug-in free live view: Chrome45.0+, Firefox52.0+ Local service: Chrome41.0+, Firefox30.0+ |
|
Interface |
: |
|
|
Ethernet Interface |
: |
1 RJ45 10M/100M self-adaptive Ethernet port |
|
On-Board Storage |
: |
Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
|
Reset Key |
: |
Yes |
|
Event |
: |
|
|
Smart Event |
: |
Line crossing detection, intrusion detecction, unattended baggage detextion, object removal detection, face detection, scene change detection |
|
General |
: |
|
|
Power |
: |
12 VDC ± 25%; PoE: 802.3af, Class 3 |
|
Material |
: |
Metal |
|
Dimension |
: |
Φ105 × 278 mm |
|
Weight |
: |
570 g |
|
Approval |
: |
|
|
Class |
: |
Class B |
|
EMC |
: |
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
|
Safety |
: |
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1) |
|
Environment |
: |
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
|
Protection |
: |
IP67 |
|
Code |
: |
PCC-296 |
