Camera |
: |
|
|
Image Sensor |
: |
1/3" (3 MP) CMOS image sensor |
|
Image Resolution |
: |
2944 × 1656 |
|
Min Illumination |
: |
0.01 lux @ ƒ/1.2, AGC on, 0 lux with IR |
|
Shutter Time |
: |
1/25 (1/30)s to 1/50,000s |
|
Len |
: |
|
|
Len Type |
: |
2.8 mm, 3.6 mm, 6 mm options |
|
Angle of view |
: |
84° (2.8 mm), 67.8° (3.6 mm), 44.6° (6 mm) |
|
Synchronization |
: |
Internal synchronization |
|
3-Axis Positioning |
: |
Pan: 0° to 360°; tilt: 0° to 75°; rotate: 0° to 360° |
|
HD Video Output |
: |
1 analog HD-TVI output |
|
Video Frame Rate |
: |
1920 × 1536 @ 18 fps (PAL/NTSC) |
|
Lens Mount |
: |
M12 |
|
Day and Night |
: |
ICR |
|
Menu |
: |
|
|
AGC |
: |
Supported |
|
D/N Mode |
: |
Color/BW/Smart |
|
White Balance |
: |
ATW/MWB |
|
BLC |
: |
Supported |
|
Functions |
: |
Wide Dynamic Range, digital noise reduction, mirror, Smart IR |
|
General |
: |
|
|
Power Supply |
: |
12 VDC ±15% |
|
IR Range |
: |
20 m |
|
Communication |
: |
Up-the-Coax, protocol: HIKVISION-C (HD-TVI output) |
|
Dimensions |
: |
91 × 82.6 × 68.3 mm |
|
Weight |
: |
350 g |
|
Protection |
: |
IP66 |
|
Code |
: |
PCC-206 |
