Encode Capability |
: |
16*1080P@15FPS/720P@30FPS/ 960H@30FPS/ D1@30FPS |
|
Decode Capability |
: |
16*1080P@15FPS/720P@30FPS/ 960H@30FPS/ D1@30FPS |
|
Multi-mode Video input |
: |
AHD High Resolution: 16CH*1080P@12FPS/ 8CH*720P@27FPS ; Hybrid: AHD High 8CH*1080P+ IPC 8CH*1080P |
|
Audio Compression |
: |
G.711A |
|
Video input |
: |
16CH BNC |
|
Video output |
: |
1 CH VGA& 1 CH HDMI |
|
Record Encode |
: |
H.264 (High Profile: Baseline/ Main Profile/ High Profile) |
|
Application/ Recording Mode |
: |
Manual, Alarm, Motion Detection, Timing |
|
Playback Search |
: |
Time, Date, Event, Channel Search |
|
Playback Display |
: |
16*1080P@12FPS |
|
Internal HDD (Storage) |
: |
1 SATA (Each Maximum Support 6TB) |
|
USB Flash Disk(Backup) |
: |
3*USB2.0 |
|
Audio Input |
: |
2 CH RCA |
|
Audio Output |
: |
1 CH RCA. |
|
Network ports |
: |
RJ45 10M/100M Self-adaptive Ethernet Port/ Support Fixed IP, DHCP, PPPoE & P2P |
|
Mobile phone |
: |
iOS & Android Supported |
|
P2P(Network) |
: |
QR Code UID Connection / App Scan |
|
PTZ Control |
: |
1 RS485ï¼›Support Multi Kinds of PTZ Protocol |
|
Remote Control |
: |
IR Remote Control & Mouse |
|
OS |
: |
Embedded Linux Supported |
|
Power Supply |
: |
12V/2A |
|
Dimensions |
: |
258mm * 219mm * 45mm |
|
Weight |
: |
1.3Kg (Include the Transformer) |
|
Code |
: |
VIRCD-253 |
