Camera |
: |
|
|
Image Sensor |
: |
5 MP CMOS image sensor |
|
Max. Resolution |
: |
2560 (H) × 1944 (V) |
|
Min. Illumination |
: |
Color: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR |
|
Shutter Time |
: |
PAL: 1/25 s to 1/50, 000 s,NTSC: 1/30 s to 1/50, 000 s |
|
Day & Night |
: |
IR cut filter |
|
Angle Adjustment |
: |
Pan: 0° to 360°; Tilt: 0° to 180°; Rotate: 0° to 360° |
|
Lens |
: |
|
|
Lens Type |
: |
2.8 mm, 3.6 mm, 6 mm fixed focal lens |
|
Focal Length & FOV |
: |
85.5° (2.8 mm), 80.1° (3.6 mm), 57.1° (6 mm) |
|
Lens Mount |
: |
M12 |
|
Image |
: |
|
|
Image Settings |
: |
Brightness, Sharpness, DNR , Mirror, Smart IR |
|
Frame Rate |
: |
PAL: 5 MP@20fps, 4 MP@25fps, 1080p@25fps,NTSC: 5 MP@20fps, 4 MP@30fps, 1080p@30fps |
|
Day/Night Mode |
: |
Auto/Color/BW (Black and White) |
|
Wide Dynamic Range (WDR) |
: |
DWDR |
|
Image Enhancement |
: |
BLC |
|
White Balance |
: |
ATW/MWB |
|
Interface |
: |
|
|
Video Output |
: |
Switchable TVI/AHD/CVI/CVBS |
|
General |
: |
|
|
Power |
: |
12 VDC ±25% |
|
IR Range |
: |
Up to 20 m |
|
Dimension |
: |
58 mm × 61 mm × 163 mm |
|
Weight |
: |
Approx. 350 g |
|
Communication |
: |
Up the coax, Protocol: HIKVISION-C (TVI output) |
|
Protection |
: |
IP67 |
|
Code |
: |
PCC-238 |
