Image Sensor |
: |
2MP CMOS Image Sensor |
|
Signal System |
: |
PAL/NTSC |
|
Image Resolution |
: |
1930(H)*1088(V) |
|
Min Illumination |
: |
0.01 Lux @ (F1.2,AGC ON),0 Lux with IR |
|
Shutter Time |
: |
1/25(1/30) s to 1/50,000 s |
|
Len |
: |
|
|
Len Type |
: |
Motorized VF lens; 2.8 - 12 mm @ F1.4 |
|
Synchronization |
: |
Internal synchronization |
|
Angle of view |
: |
114.5° - 35.1° |
|
HD Video Output |
: |
1 Analog HD output |
|
Video Frame Rate |
: |
1080p@25fps/1080p@30fps |
|
Lens Mount |
: |
φ14 |
|
Day and Night |
: |
ICR |
|
Menu |
: |
|
|
Camera ID |
: |
On/off (0-255) |
|
D/N Mode |
: |
Color/BW/Auto/EXT |
|
White Balance |
: |
Auto/User/Push/8000K/6000K/4200K/3000K |
|
Anti-Flicker |
: |
On/Off |
|
Functions |
: |
Digital noise reduction, Mirror |
|
General |
: |
|
|
Power Supply |
: |
12 VDC±15% -A: 12 VDC±15%, 24 VAC±15% |
|
IR Range |
: |
Up to 40m |
|
Communication |
: |
Up the coax Protocol: HIKVISION-C(Coaxitron) |
|
Dimensions |
: |
Φ 145.2 × 124.1 mm |
|
Weight |
: |
920 g |
|
Protection |
: |
IP66 |
|
Code |
: |
PCC-144 |
