Frequency Bands |
: |
LTE -B1/B3/B5/B7/B8/B20/B38/B40 UMTS - Band 1, 8 GSM - 850/900/1800 MHz |
|
Bandwidth |
: |
LTE Band - 1.4/3/5/10/15/20 MHz, comply with 3GPP |
|
Modulation |
: |
Downlink - QPSK/16-QAM/64-QAM, comply with 3GPP Uplink - QPSK/16-QAM, comply with 3GPP |
|
Data Rate |
: |
4G - 3GPP Cat. 4, Downlink/Uplink up to 150Mbps/50Mbps 3G - 3GPP Downlink/Uplink up to 42Mbps/5.76Mbps 3G - 3GPP2 Downlink/Uplink up to 3.1Mbps/1.8Mbps (MDM9607 only) 2G - EGPRS Class33 Downlink/Uplink up to 296Kbps/236.8Kbps |
|
WLAN |
: |
Frequency - 2.4GHz Protocol - 802.11b/g/n, 20/40M Channel 1 ~ 11 Antenna - Internal Antenna ( 2 x 2 ) |
|
Interface |
: |
2x 1000Mbps LAN 1x 1000Mbps LAN + 1x 1000Mbps WAN (Optional) RJ11 - CS Voice, VoLTE (Subject to local carrier support) USIM - Single, 2FF Antenna - 2x LTE External Antenna Power Jack - DC Input (12V 1A) |
|
Dimension |
: |
120 x 55 x 117mm |
|
Weight |
: |
180g |
|
Code |
: |
ROPL-07 |
