Camera |
: |
|
|
Image Sensor |
: |
1/2.9" Progressive Scan CMOS |
|
Max. Resolution |
: |
2944 × 1656 |
|
Min. Illumination |
: |
Color: 0.01 lux @(F1.2, AGC ON), 0.028 Lux @(F2.0, AGC ON), B/W: 0 lux with IR |
|
Shutter Time |
: |
1/3 s to 1/100,000 s |
|
Day & Night |
: |
IR cut filter |
|
Angle Adjustment |
: |
Pan: 0° to 355° , tilt: 0° to 75°, rotate: 0° to 355° |
|
Lens |
: |
|
|
Lens Type |
: |
Fixed focal lens, 2.8, 4, and 6 mm optional |
|
Focal Length & FOV |
: |
2.8 mm, horizontal FOV: 97° 4 mm, horizontal FOV: 78° 6 mm, horizontal FOV: 60° |
|
Lens Mount |
: |
M12 |
|
Iris Type |
: |
Fixed |
|
Aperture |
: |
F2.0 |
|
Illuminator |
: |
|
|
Supplement Light Type |
: |
IR |
|
Supplement Light Range |
: |
Up to 30 m |
|
Image |
: |
|
|
Image Settings |
: |
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance adjustable by client software or web browser |
|
Day/Night Mode |
: |
Day/Night/Auto/Schedule/Triggered by Alarm In(-S) |
|
Wide Dynamic Range (WDR) |
: |
120 dB |
|
Image Enhancement |
: |
BLC/3D DNR/HLC |
|
Video |
: |
|
|
Main Stream |
: |
50 Hz: 20 fps (2944 × 1656), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720) 60 Hz: 20 fps (2944 × 1656), 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
|
Sub-Stream |
: |
50 Hz: 25 fps (640 × 480, 640 × 360, 320 × 240) 60 Hz: 30 fps (640 × 480, 640 × 360, 320 × 240) |
|
Video Compression |
: |
Main stream: H.265+/H.265/H.264+/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 |
|
Video Bit Rate |
: |
32 Kbps to 16 Mbps |
|
H.264 Type |
: |
Main Profile/High Profile |
|
H.265 Type |
: |
Main Profile |
|
Nework |
: |
|
|
Protocols |
: |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
|
Simultaneous Live View |
: |
Up to 6 channels |
|
API |
: |
Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK |
|
User/Host |
: |
Up to 32 users. 3 user levels: administrator, operator and user |
|
Client |
: |
iVMS-4200, Hik-Connect, Hik-Central |
|
Web Browser |
: |
Plug-in required live view: IE8+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+ Local |
|
Interface |
: |
|
|
Ethernet Interface |
: |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
|
On-Board Storage |
: |
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 128 GB |
|
Audio |
: |
1 audio input (line in), 1 audio output interface, mono sound, terminal block |
|
Alarm |
: |
1 alarm input, 1 alarm output (max. 12 VDC, 30 mA), terminal block |
|
Reset Key |
: |
Yes |
|
Event |
: |
|
|
Basic Event |
: |
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) |
|
Linkage |
: |
Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output (-S), Email |
|
Smart Event |
: |
Line crossing detection, intrusion detection, unattended baggage detection, object removal detection, face detection, scene change detection |
|
General |
: |
|
|
Power |
: |
12 VDC ± 25%, 6.2 W PoE: 802.3af, class 3, 36 V to 57 V, 9 W |
|
Dimension |
: |
Ø111 × 82.4 mm |
|
Weight |
: |
500 g |
|
Approval |
: |
|
|
Protection |
: |
IP67 (IEC 60529-2013) IK10 (IEC 62262: 2002) |
|
Code |
: |
PCC-226 |
