IP Video Input |
: |
8-ch |
|
Incoming Bandwidth |
: |
80 Mbps |
|
Outgoing Bandwidth |
: |
80 Mbps |
|
HDMI Output |
: |
1-ch, 4K (4096 x 2160)/30 Hz, 4K (3840 x 2160)/30 Hz, 2K (2560 x 1440)/60 Hz, 1920 x 1080/60 Hz, 1600 x 1200/60 Hz, 1280 x 1024/60 Hz, 1280 x 720/60 Hz |
|
VGA Output |
: |
1-ch, 1920 × 1080/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz |
|
Video Output Mode |
: |
HDMI/VGA simultaneous output |
|
Audio Output |
: |
1-ch, RCA (Linear, 1 KΩ) |
|
Two-Way Audio |
: |
1-ch, RCA (2.0 Vp-p, 1kΩ) |
|
Stream Type |
: |
Video, Video & Audio |
|
Audio Compression |
: |
G.711ulaw/G.711alaw/G.722/G.726 |
|
Decoding Format |
: |
H.265+/H.265/H.264+/H.264 |
|
Recording Resolution |
: |
8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/ 720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
|
Decoding Capability |
: |
1-ch@8 MP (30 fps)/3-ch@4 MP (30 fps)/6-ch@1080p (30 fps) *: The length or width of camera resolution (each track) cannot exceed 4096 pixels. |
|
Synchronous playback |
: |
8-ch |
|
Network Protocol |
: |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS |
|
Network Interface |
: |
1 RJ-45 10 /100 Mbps self-adaptive Ethernet interface |
|
Auxiliary Interface |
: |
SATA: 1 SATA interface |
|
|
: |
Capacity: Up to 8 TB capacity for each disk |
|
|
: |
USB Interface: 2 × USB 2.0 |
|
|
: |
Alarm In/Out: N/A (4/1 is optional) |
|
Power Supply |
: |
12 VDC, 1.5 A |
|
Dimension |
: |
320 × 240 × 48 mm |
|
Weight |
: |
1 kg |
|
Code |
: |
VIRCD-278 |
