Camera |
: |
|
|
Image Sensor |
: |
3MP CMOS Image Sensor |
|
Max. Resolution |
: |
2052(H)*1536(V) |
|
Min. Illumination |
: |
0.01 Lux @ (F1.2,AGC ON), 0 Lux with IR |
|
Shutter Time |
: |
1/25(1/30)s to 1/50,000s |
|
Day & Night |
: |
ICR |
|
Angle Adjustment |
: |
Pan: 0° - 360°; Tilt:0° - 90°; Rotate: 0° - 360° |
|
Signal System |
: |
|
|
Lens |
: |
|
|
Lens Type |
: |
2.8mm, 3.6mm, 6mm, 8mm, 12mm, 16mm optional |
|
Angle of View |
: |
84°(2.8mm), 67.8°(3.6mm), 44.6°(6mm), 31.6°(8mm), 20.2°(12mm), 15.8°(16mm) |
|
Lens Mount |
: |
M12 |
|
Video |
: |
|
|
HD Video Output |
: |
1 Analog HD output |
|
Video Frame Rate |
: |
1920×1536@18fps |
|
WDR |
: |
120dB |
|
S/N Ratio |
: |
＞62dB |
|
D/N Mode |
: |
Color/BW/SMART |
|
White Balance |
: |
ATW/ MWB |
|
Functions |
: |
Wide Dynamic Range, Digital noise reduction, Mirror, SMART IR |
|
General |
: |
|
|
Power |
: |
12 VDC±15% |
|
Dimension |
: |
86.7mm×81.6mm×226mm |
|
Weight |
: |
Approx. 680g |
|
Communication |
: |
Up the coax, Protocol: HIKVISION-C (TVI output) |
|
Approval |
: |
|
|
Protection |
: |
IP66 |
|
Code |
: |
PCC-175 |
