Camera |
: |
|
|
Image Sensor |
: |
5 MP CMOS |
|
Max. Resolution |
: |
2560 (H) × 1944 (V) |
|
Min. Illumination |
: |
0.01 Lux@(F2.0, AGC ON), 0 Lux with IR |
|
Shutter Time |
: |
PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s |
|
Day & Night |
: |
ICR |
|
Angle Adjustment |
: |
Pan: 0 to 355°, Tilt: 0 to 75°, Rotation 0 to 355° |
|
Signal System |
: |
PAL/NTSC |
|
Lens |
: |
|
|
Lens Type |
: |
2.8 mm, 3.6 mm, 6 mm fixed lens |
|
Focal Length & FOV |
: |
2.8 mm, horizontal FOV: 85.5°,vertical FOV: 63.7°, diagonal FOV: 110.7° 3.6 mm, horizontal FOV: 80.1°, vertical FOV: 63.7°, diagonal FOV: 105.9° 6 mm, horizontal FOV: 57.1°, vertical FOV: 43.1°, diagonal FOV: 72.5° |
|
Lens Mount |
: |
M12 |
|
Image |
: |
|
|
Image Parameters Switch |
: |
|
|
Image Settings |
: |
Brightness, Sharpness, Mirror, Smart IR |
|
Frame Rate |
: |
TVI: 5MP@20fps, 4MP@30fps, 4MP@25fps, 1080P@30fps, 1080P@25fps CVI: 4MP@30fps, 4MP@25fps AHD: 5MP@20fps, 4MP@30fps, 4MP@25fps CVBS: PAL/NTSC |
|
Day/Night Mode |
: |
Auto/Color/BW (Black and White) |
|
Image Enhancement |
: |
BLC |
|
White Balance |
: |
ATW/MANUAL |
|
Noise Reduction |
: |
2D DNR |
|
Interface |
: |
|
|
Video Output |
: |
Switchable TVI/AHD/CVI/CVBS |
|
General |
: |
|
|
Power |
: |
12 VDC ± 25% *You are recommended to use one power adapter to supply the power for one camera |
|
Material |
: |
Plastic |
|
Dimension |
: |
58 mm × 61 mm × 158.6 mm |
|
Weight |
: |
Approx. 160 g |
|
Communication |
: |
HIKVISION-C |
|
Approval |
: |
|
|
Protection |
: |
IP67 |
|
Code |
: |
PCC-293 |
