CPU Socket Suport |
: |
Intel® Socket 1200 |
|
Chipset |
: |
Intel® Z490 |
|
Memory |
: |
4 x DIMM, Max. 128GB, DDR4 |
|
Graphics |
: |
1 x HDMI™ port *, 1 x DisplayPort 1.4 ** |
|
Expansion Slots |
: |
1 x PCIe 3.0 x16 (max at x4 mode) *2 |
|
|
: |
1 x PCIe 3.0 x16 (x16 mode) *1 |
|
Storage |
: |
2 x M.2_1 socket 3, with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode) |
|
|
: |
6 x SATA 6Gb/s port(s) |
|
Ethernet |
: |
Intel® I225-V 2.5Gb Ethernet |
|
Wireless & Bluetooth |
: |
None |
|
USB |
: |
1 x USB 3.2 Gen 2 port(s)(1 x USB Type-C®) |
|
|
: |
Rear USB Port ( Total 8 ) |
|
|
: |
4 x USB 3.2 Gen 1 port(s)(4 x Type-A) |
|
|
: |
Front USB Port ( Total 7 ) |
|
|
: |
2 x USB 3.2 Gen 1 port(s)(2 x Type-A) |
|
|
: |
2 x USB 3.2 Gen 2 port(s)(1 x Type-A +1 x USB Type-C®) |
|
|
: |
2 x USB 2.0 port(s) |
|
|
: |
4 x USB 2.0 port(s) |
|
Audio |
: |
ROG SupremeFX8-Channel High Definition Audio CODEC S1220A |
|
Internal I/ Connetior |
: |
1 x M.2 Socket 1 with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode) |
|
|
: |
1 x USB 3.2 Gen2 connector support additional 1 USB ports(20-pin, Type-C) |
|
|
: |
1 x VRM_HS_FAN Header |
|
|
: |
1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) |
|
|
: |
1 x CPU OV |
|
|
: |
1 x CPU Fan connector(s) |
|
|
: |
1 x CPU OPT Fan connector(s) |
|
|
: |
2 x Chassis Fan connector(s) |
|
|
: |
1 x W_PUMP+ connector |
|
|
: |
2 x Aura RGB Strip Headers |
|
|
: |
2 x Addressable Gen 2 header(s) |
|
|
: |
1 x 24-pin EATX Power connector(s) |
|
|
: |
1 x 8-pin ATX 12V Power connector(s) |
|
|
: |
1 x 4-pin ATX 12V Power connector(s) |
|
|
: |
1 x Thermal sensor connector(s) |
|
|
: |
1 x Clear CMOS jumper(s) |
|
Back Panel Connectors |
: |
2 x USB 3.2 Gen 2 (1 x Type-A+1 x USB Type-C®) |
|
|
: |
1 x Intel® I225-V 2.5Gb Ethernet |
|
|
: |
1 x USB BIOS FlashBack™ Button(s) |
|
|
: |
4 x USB 3.2 Gen 1 Type-A |
|
|
: |
1 x DisplayPort |
|
|
: |
1 x HDMI |
|
|
: |
2 x USB 2.0 |
|
|
: |
1 x Optical S/PDIF out |
|
|
: |
5 x Gold-plated audio jacks |
|
Form Factor |
: |
mATX Form Factor 24.4 cm x 24.4 cm |
|
Code |
: |
MBASUS-18 |
