CPU Socket Suport |
: |
Intel® Socket LGA1200 |
|
Chipset |
: |
Z590 |
|
Memory |
: |
4-DIMM DDR4 2666MHz. |
|
Graphics |
: |
1x DisplayPort 1.4, 1x HDMI™ 2.0 |
|
Expansion Slots |
: |
2 x PCIe 4.0/3.0 x16 (x16, x8/x8, x8/x4) + 1 x PCIe 3.0 x16 (max. x4) |
|
|
: |
2 x PCIe 4.0/3.0 x16 slot(s)* |
|
Storage |
: |
4 x M.2 slots |
|
|
: |
6 x SATA 6Gb/s ports |
|
Ethernet |
: |
2 x Intel® 2.5Gb Ethernet |
|
Wireless & Bluetooth |
: |
2x2 Tri-Band Intel Wi-Fi a/b/g/n/ac/ax/az + BT5.2 |
|
USB |
: |
Rear USB:Total 10 ports |
|
|
: |
1 x USB 3.2 Gen 2x2 port(s) (1 x USB Type-C®) |
|
|
: |
3 x USB 3.2 Gen 2 port (2 x Type-A, 1 x USB Type-C® ) |
|
|
: |
4 x USB 3.2 Gen 1 port (4 x Type-A) |
|
|
: |
2 x USB 2.0 port(s) (2 x Type-A) |
|
|
: |
1 x USB 3.2 Gen 1 header |
|
|
: |
2 x USB 2.0 header(s) |
|
Audio |
: |
SupremeFX Shielding Technology |
|
Internal I/ Connetior |
: |
Fan and Cooling related |
|
|
: |
1 x 4-pin CPU Fan header(s) |
|
|
: |
1 x 4-pin CPU OPT Fan header(s) |
|
|
: |
1 x 4-pin AIO Pump header(s) |
|
|
: |
3 x 4-pin Chassis Fan header(s) |
|
|
: |
1 x VRM heatsink Fan header |
|
|
: |
1 x W_PUMP+ header |
|
|
: |
Power related |
|
|
: |
1 x 24-pin Main Power connector |
|
|
: |
1 x 8-pin +12V Power connector |
|
|
: |
1 x 4-pin +12V Power connector |
|
|
: |
Miscellaneous |
|
|
: |
3 x AURA Addressable Gen 2 header(s) |
|
|
: |
1 x AURA RGB header(s) |
|
|
: |
1 x Q Code |
|
|
: |
1 x SPI TPM header (14-1pin) |
|
|
: |
1 x 20-3 pin System Panel header with Chassis intrude function |
|
|
: |
1 x Thermal Sensor header |
|
|
: |
1 x Thunderbolt header |
|
Back Panel Connectors |
: |
1 x USB 3.2 Gen 2x2 port (1 x USB Type-C®) |
|
|
: |
3 x USB 3.2 Gen 2 port(s) (2 x Type-A, 1 x USB Type-C® ) |
|
|
: |
4 x USB 3.2 Gen 1 port(s) (4 x Type-A) |
|
|
: |
2 x USB 2.0 port(s) (2 x Type-A) |
|
|
: |
1 x HDMI™ port |
|
|
: |
1 x DisplayPort |
|
|
: |
1 x Intel® Wi-Fi 6E |
|
|
: |
2 x Intel® I225-V 2.5Gb Ethernet |
|
|
: |
1 x Optical S/PDIF out port |
|
|
: |
1 x Clear CMOS button |
|
Form Factor |
: |
ATX 30.5cm x 24.4cm |
|
Code |
: |
MBASUS-22 |
