UPS Type |
: |
Tower |
|
Capacity |
: |
3000VA / 2700W |
|
Dimension(mm) |
: |
282 x 145 x 220 |
|
Communication |
: |
Smart RS232 and USB port |
|
Fron Panel |
: |
Status LED, function keys, LCD display |
|
LCD Indicators |
: |
Load level, battery level, AC mode, battery mode, bypass mode, and fault indicators |
|
Input |
: |
|
|
Nominal Voltage |
: |
200/208/220/230/240VAC |
|
Voltage Rang |
: |
"110-300VAC (Based on load at 50%), 160-280VAC (Based on load at 100%)" |
|
Nominal Frequency |
: |
40 - 70Hz |
|
Power Factor |
: |
≧ 0.99 @ nominal voltage (100% load) |
|
Output |
: |
|
|
Output voltage regulation |
: |
±1% |
|
Frequency Rage (synchronized Rage) |
: |
Synchronized range: 47 - 53Hz or 57 - 63Hz |
|
Frequency Rage (Batt. Mode) |
: |
Battery mode: 50Hz ± 0.25Hz or 60Hz ± 0.3Hz |
|
Batttery |
: |
|
|
Number of Battery |
: |
12V/9Ah x 6pcs |
|
Recharge Time (typical) |
: |
4 hours to 90% capacity |
|
Alarm |
: |
Battery mode - Sounding every 4 seconds |
|
|
: |
Low battery - Sounding every second |
|
|
: |
Overload - Sounding twice every second |
|
|
: |
Faulty - Continuously sounding |
|
Code |
: |
UPPL-48 |
