CPU Socket Suport |
: |
LGA1700 for Intel® Core™ 14th, 13th & 12th Gen |
|
Chipset |
: |
Intel® B760 Chipset |
|
Memory |
: |
4 x DIMM slots, Max. 192GB, DDR5 7800+ |
|
Graphics |
: |
1 x Display, 1 x HDMITM |
|
Expansion Slots |
: |
Intel® Core™ Processors (14th & 13th & 12th Gen) |
|
|
: |
1 x PCIe 5.0 x16 slot |
|
|
: |
Intel® B760 Chipset |
|
|
: |
1 x PCIe 3.0 x16 slot (supports x4 mode) |
|
|
: |
2 x PCIe 3.0 x1 slots |
|
Storage |
: |
3 x M.2 slots |
|
|
: |
4 x SATA 6Gb/s |
|
Ethernet |
: |
1 x Intel® 2.5Gb Ethernet |
|
Wireless & Bluetooth |
: |
Wi-Fi 6E 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax) + Bluetooth® v5.3 |
|
USB |
: |
Rear USB (Total 9 ports) |
|
|
: |
1 x USB 3.2 Gen 2x2 (20G) port (1 x USB Type-C®) |
|
|
: |
1 x USB 3.2 Gen 2 (10G) port (1 x Type-A) |
|
|
: |
3 x USB 3.2 Gen 1 (5G) port (2 x Type-A, 1 x USB Type-C®) |
|
|
: |
4 x USB 2.0 ports (4 x Type-A) |
|
|
: |
Front USB (Total 6 ports) |
|
|
: |
1 x USB 3.2 Gen 2 (10G) connector (supports USB Type-C®) |
|
|
: |
1 x USB 3.2 Gen 1 (5G) header supports 2 additional USB 3.2 Gen 1 ports |
|
|
: |
1 x USB 2.0 header and 1 x USB 2.0 5-1 pin header support 3 additional USB 2.0 ports |
|
Audio |
: |
ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080 |
|
Back Panel I/O Ports |
: |
1 x USB 3.2 Gen 2x2 (20G) port (1 x USB Type-C®) |
|
|
: |
1 x USB 3.2 Gen 2 (10G) port (1 x Type-A) |
|
|
: |
3 x USB 3.2 Gen 1 (5G) ports (2 x Type-A, 1 x USB Type-C®) |
|
|
: |
4 x USB 2.0 ports (4 x Type-A) |
|
|
: |
1 x DisplayPort |
|
|
: |
1 x HDMI™ port |
|
|
: |
1 x Wi-Fi Module |
|
|
: |
1 x Intel® 2.5Gb Ethernet port |
|
|
: |
5 x Audio jacks |
|
|
: |
1 x BIOS FlashBack™ button |
|
Internal I/O Connectors |
: |
Fan and Cooling related |
|
|
: |
1 x 4-pin CPU Fan header |
|
|
: |
1 x 4-pin CPU OPT Fan header |
|
|
: |
1 x 4-pin AIO Pump header |
|
|
: |
4 x 4-pin Chassis Fan headers |
|
|
: |
Power related |
|
|
: |
1 x 24-pin Main Power connector |
|
|
: |
1 x 8-pin +12V Power connector |
|
|
: |
1 x 4-pin +12V Power connector |
|
|
: |
Storage related |
|
|
: |
3 x M.2 slots (Key M) |
|
|
: |
4 x SATA 6Gb/s ports |
|
|
: |
USB |
|
|
: |
1 x USB 3.2 Gen 2 (10G) connector (supports USB Type-C® ) |
|
|
: |
1 x USB 3.2 Gen 1 (5G) header supports 2 additional USB 3.2 Gen 1 ports |
|
|
: |
1 x USB 2.0 header and 1 x USB 2.0 5-1 pin header support 3 additional USB 2.0 ports |
|
|
: |
Miscellaneous |
|
|
: |
3 x Addressable Gen 2 headers |
|
|
: |
1 x Aura RGB header |
|
|
: |
1 x Clear CMOS header |
|
|
: |
1 x Front Panel Audio header (AAFP) |
|
|
: |
1 x S/PDIF Out header |
|
|
: |
1 x 20-5 pin System Panel header |
|
|
: |
1 x Thermal Sensor header |
|
|
: |
1 x Thunderbolt™ (USB4®) header |
|
Special Features |
: |
Extreme Engine Digi+ |
|
|
: |
- 5K Black Metallic Capacitors |
|
|
: |
|
|
|
: |
ASUS Q-Design |
|
|
: |
- M.2 Q-Latch |
|
|
: |
- PCIe Slot Q-Release |
|
|
: |
- Q-DIMM |
|
|
: |
- Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) |
|
|
: |
- Q-Slot |
|
|
: |
ASUS Thermal Solution |
|
|
: |
- M.2 heatsink |
|
|
: |
- VRM heatsink design |
|
|
: |
ASUS EZ DIY |
|
|
: |
- BIOS FlashBack™ button |
|
|
: |
- BIOS FlashBack™ LED |
|
|
: |
- CPU Socket lever protector |
|
|
: |
- ProCool |
|
|
: |
- Pre-mounted I/O shield |
|
|
: |
- SafeSlot |
|
|
: |
- SafeDIMM |
|
|
: |
Aura Sync |
|
|
: |
- Aura RGB header |
|
|
: |
- Addressable Gen 2 headers |
|
BIOS |
: |
256 Mb Flash ROM, UEFI AMI BIOS |
|
Dimension |
: |
30.5 cm x 24.4 cm |
