CPU Socket Suport |
: |
AM5 for AMD Ryzen 9000 , 8000, 7000Series |
|
Chipset |
: |
AMD X870 |
|
Memory |
: |
4 x DIMM up to 8000+MT/s(OC) |
|
Graphics |
: |
1 x HDMI™ port*, 2 x USB4® (40Gbps) |
|
Expansion Slots |
: |
AMD Ryzen™ 9000 & 7000 Series |
|
|
: |
1 x PCIe 5.0 x16 slot (supports x16 mode) |
|
|
: |
AMD Ryzen™ 8000 Series |
|
|
: |
1 x PCIe 4.0 x16 slot (supports x8/x4 mode) |
|
|
: |
AMD X870 Chipset |
|
|
: |
3 x PCIe 4.0 x16 slots (support x1 mode) |
|
Storage |
: |
4 x M.2 slots 1Slote Suport 80mm, 60mm, 42mm |
|
|
: |
2 x SATA 6Gb/s ports |
|
Ethernet |
: |
1 x Realtek 2.5Gb Ethernet ASUS LANGuard |
|
Wireless & Bluetooth |
: |
Wi-Fi 7* 2x2 Wi-Fi 7 (802.11be) Bluetooth® v5.4*** |
|
USB |
: |
Rear USB (Total 10 ports) |
|
|
: |
2 x USB4® (40Gbps) ports (2 x USB Type-C®) |
|
|
: |
1 x USB 10Gbps port (1 x Type-A) |
|
|
: |
3 x USB 5Gbps ports (3 x Type-A) |
|
|
: |
4 x USB 2.0 ports (4 x Type-A) |
|
|
: |
Front USB (Total 7 ports) |
|
|
: |
1 x USB 10Gbps connector (supports USB Type-C®) |
|
|
: |
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports |
|
|
: |
2 x USB 2.0 headers support 4 additional USB 2.0 ports |
|
|
: |
* USB Type-C® power delivery output: max. 5V/3A |
|
Audio |
: |
Realtek 7.1 Surround Sound High Definition Audio CODEC* |
|
Back Panel I/O Ports |
: |
2 x USB4® (40Gbps) ports (2 x USB Type-C®) |
|
|
: |
1 x USB 10Gbps port (1 x Type-A) |
|
|
: |
3 x USB 5Gbps ports (3 x Type-A) |
|
|
: |
4 x USB 2.0 ports (4 x Type-A) |
|
|
: |
1 x HDMI™ port |
|
|
: |
1 x Wi-Fi module |
|
|
: |
1 x Realtek 2.5Gb Ethernet port |
|
|
: |
3 x Audio jacks |
|
|
: |
1 x BIOS FlashBack™ button |
|
Internal I/O Connectors |
: |
Fan and Cooling Related |
|
|
: |
1 x 4-pin CPU Fan header |
|
|
: |
1 x 4-pin CPU OPT Fan header |
|
|
: |
1 x 4-pin AIO Pump header |
|
|
: |
4 x 4-pin Chassis Fan headers |
|
|
: |
Power Related |
|
|
: |
1 x 24-pin Main Power connector |
|
|
: |
2 x 8-pin +12V CPU Power connectors |
|
|
: |
Storage Related |
|
|
: |
4 x M.2 slots (Key M) |
|
|
: |
2 x SATA 6Gb/s ports |
|
|
: |
USB |
|
|
: |
1 x USB 10Gbps connector (supports USB Type-C®) |
|
|
: |
1 x USB 5Gbps header supports 2 additional USB 5Gbps ports |
|
|
: |
2 x USB 2.0 headers support 4 additional USB 2.0 ports |
|
|
: |
Miscellaneous |
|
|
: |
3 x Addressable Gen 2 headers |
|
|
: |
1 x Clear CMOS header |
|
|
: |
1 x COM Port header |
|
|
: |
1 x Front Panel Audio header (F_AUDIO) |
|
|
: |
1 x S/PDIF Out header |
|
|
: |
1 x SPI TPM header (14-1 pin) |
|
|
: |
1 x 10-1 pin System Panel header |
|
Special Features |
: |
ASUS 5X PROTECTION III |
|
|
: |
- DIGI+ VRM (- Digital power design with DrMOS) |
|
|
: |
- LANGuard |
|
|
: |
- Overvoltage protection |
|
|
: |
- SafeSlot |
|
|
: |
- Stainless-steel back I/O |
|
|
: |
ASUS Q-Design |
|
|
: |
- M.2 Q-Latch |
|
|
: |
- PCIe Slot Q-Release |
|
|
: |
- Q-Antenna |
|
|
: |
- Q-Dashboard |
|
|
: |
- Q-DIMM |
|
|
: |
- Q-LED Core |
|
|
: |
- Q-Slot |
|
|
: |
ASUS Thermal Solution |
|
|
: |
- Flexible M.2 heatsink |
|
|
: |
- VRM heatsink design |
|
|
: |
ASUS EZ DIY |
|
|
: |
- BIOS FlashBack™ button |
|
|
: |
- BIOS FlashBack™ LED |
|
|
: |
- ProCool |
|
|
: |
- Pre-mounted I/O shield |
|
|
: |
- SafeSlot |
|
|
: |
Aura Sync |
|
|
: |
- Addressable Gen 2 headers |
|
BIOS |
: |
256 Mb Flash ROM, UEFI AMI BIOS |
|
Dimension |
: |
30.5 cm x 24.4 cm |
|
Form Factor |
: |
ATX |
