Camera |
: |
|
|
Image Sensor |
: |
2MP CMOS Image Sensor |
|
Max. Resolution |
: |
1928(H)*1088(V) |
|
Min. Illumination |
: |
0.01 Lux @ (F1.2,AGC ON),0 Lux with IR |
|
Shutter Time |
: |
1/25(1/30)s to 1/50,000s |
|
Day & Night |
: |
ICR |
|
Angle Adjustment |
: |
Pan: 0° - 360°; Tilt: 0° - 75°; Rotate: 0° - 360° |
|
Signal System |
: |
PAL/NTSC |
|
Lens |
: |
|
|
Lens Type |
: |
2.8mm, 3.6mm, 6mm, 8mm, 12mm, 16mm optional |
|
Angle of View |
: |
103°(2.8mm), 82.2°(3.6mm), 54°(6mm), 37.7°(8mm), 24.3°(12mm), 18.8°(16mm) |
|
Lens Mount |
: |
M12 |
|
Video |
: |
|
|
Video Frame Rate |
: |
1080p@25fps/1080p@30fps |
|
HD Video Output |
: |
1 Analog HD output |
|
S/N Ratio |
: |
＞62dB |
|
General |
: |
|
|
Power |
: |
12 VDC±15% |
|
IR Range |
: |
Up to 40m |
|
Dimension |
: |
φ110mm×93.2mm |
|
Weight |
: |
Approx. 350g |
|
Approval |
: |
|
|
Protection |
: |
IP66 |
|
Code |
: |
PCC-202 |
